Linksys WiFi Extender Setup for ac1200

Linksys extender setup for ac1200 can be done in two different ways, either you can use the browser setup or you can also choose the WPS that is, WiFi protected setup. Both setups are equally efficient for Linksys extender setup ac1200.

Linksys WiFi Extender Setup for ac1200: Browser Based Setup

Here are the steps for setup the Linksys extender ac1200 using the browser based instructions. Before you proceed for the next steps, make sure you have information regarding SSID that is Wireless Network Name and the security Password.

• First you will need to connect the antennas with Linksys extender ac1200 and connect the power adapter.

• Now you will need to place the Linksys ac1200 WiFi extender at desired location. You will need to place the WiFi range extender at a mid location, that is, area between your Linksys router and the dead zones you are facing.

• You will notice that the LED located at the top of the Linksys extender ac1200 will lit. If LED is lit, you can go for the next steps for Linksys extender setup ac1200.
• At this step you will need to connect the ac1200 extender with your router device.

Either you can go for the wireless setup or you can also go for the wired setup.

For Wireless Setup: for the wireless setup for Linksys extender ac1200, you will need to get connected with the WiFi network Linksys Extender Setup – “Last Three Words for Extender MAC Address”.

For Wired Connections: wired connection can be made using the Ethernet cable. Connect one end to any port provide at the backside of WiFi extender and connect another end with the system you will use for the Linksys extender setup ac1200.

• After making all these connections, open the web browser and access the Linksys extender setup ac1200 page. Fill the local address http://extender.linksys.com in the address bar and press enter key. If you are facing issues with the local address access, go for the IP address 192.168.1.1
• After filling the login details, you will be landed on the WiFi extender setup page. Click on the “Start” button.

• You have to agree for the License Agreement if you want to proceed for the next steps regarding Linksys extender setup ac1200.
• Choose the desired wireless network and get connected with it.
• Best thing about Linksys extender ac1200 is that, you will be provided with the “Spot Finder” option. Using this feature, you can easily find the desired location for placing your WiFi extender.
• You can proceed for the next steps after filling the required password.
• Here you can go for the advance settings and configurations regarding Linksys extender setup ac1200.

From here, our team will suggest you for the advance configurations. Further setup can be little bit complicated, try contacting using the Toll Free Number we have provided in the contact page or you can also drop your query to our experts.
